| Specification | |
| Circuits | 1-7 circuits |
| Work Speed | 0-300RPM |
| Work Temperature | -20℃-+60℃ |
| Work Humidity | 60%RH or higher |
| Voltage Rating | 240VAC/DC |
| Current Rating | 2A per circuit |
| Through Hole Size | 2-10mm |
| Dielectric Strength | 500VAC@50Hz between each circuit |
| Electrical Noise | 1mΩ Min |
| Contact Materials | Gold to gold |
| Lead Wire Size | AWG26 Teflon® UL |
| Lead Wire Length | Standard 250mm |
| Housing Materials | Engineering Plastic |
| Torque | ≤0.88 gm ( for reference） |
| Protection | IP54 or higher |
Barlin Times will be highly welcome your contact if you would like to get more details or special specification. Looking forward to your kind cooperation in the near future. Thanks.
